100A MPPT 12V/24V Dual USB Solar Panel Battery Charge Controller LCD

100A MPPT 12V/24V Dual USB Solar Panel Battery Charge Controller LCD Regulator BUY WITH CONFIDENCE ^ - ^ ★  Add our store to your Favorites, you will get a special gift :) ★  100% New & Excellent Quality ★ Free 1-4 days from NJ,USA.Ship within 24 Hours. ★  Offer delivery with Tracking Number ★  Each set will be fully tested before shipping ★  Free Return,Seller pay!! ★ Lifetime Warranty Features: 1.Build-in industrial micro controller. 2.Big LCD display,all adjustable controlling parameter of the system. 3.Fully 4-stage PWM charge management. 4.Build-in all necessory protections including short-circuit protection,open-circuit protection,reverse protection,over-load protection. 5.Dual mosfet Reverse current protection ,low heat production LCD display/key and Operations: MENU:Switch between different display,or to enter/exit setting by long press. UP: Press to increase value. DOWN:Press to decrease value. System Connection: 1.Connect the battery to the charge regulator - plus and minus. 2.Connect the photovoltaic module to the regulator - plus and minus. 3.Connect the consumer to the charge regulator - plus and minus. *The reverse order applies when deinstalling! *An improper sequence order can damage the controller! Attention: 1.press the [Down] button to ON/OFF load manully at main display. 2.the work mode is working as below: [24H] load output 24hours [1-23H] load on after sunset and closed after setting hours [0H] Dusk to dawn 3.Batteries:Only fit for OPEN, AGM, GEL 4.The charge regulator is only suitable for,regulating solar modules Never connect another charging source to the charge regulator. 5.Please make sure your battery has enough voltage for the controller to recognize the battery type before first installation. Specifications of 30 A: Load: Light Control MPN: RBL Charging Mode:PWM Model:RBL-30A System Voltage:12V 24V Max Solar input(Solar Panel):36V(24V battery) 18V(12V battery) Max input power: 390W(12V system); 780W(24V system) Equalization:12.6V(sealed) 14.2V(Gel) 14.6V(flood) Float charge:13.7V(defaul,adjustable)，12.0-15.0V Discharge stop voltage:10.7V(defaul,adjustable)，9.0-11.5V Discharge reconnect voltage:12.5V(defaul,adjustable)，11.0-13.0V Rated current: 30A Self-consume:<10mA Batteries:Only fit for OPEN, AGM, GEL Operating Temperature:-35℃~60℃ USB output:5V/2A Max Dimension:13.4*7*3.3cm Specifications of 60 A: Load: Light Control MPN: RBL Charging Mode:PWM Model:RBL-60A System Voltage:12V 24V Max Solar input(Solar Panel):36V(24V battery) 18V(12V battery) Max input power: 750W(12V system); 1500W(24V system) Equalization:12.6V(sealed) 14.2V(Gel) 14.6V(flood) Float charge:13.7V(defaul,adjustable)，12.0-15.0V Discharge stop voltage:10.7V(defaul,adjustable)，9.0-11.5V Discharge reconnect voltage:12.5V(defaul,adjustable)，11.0-13.0V Rated current: 60A Self-consume:<10mA Batteries:Only fit for OPEN, AGM, GEL Operating Temperature:-35℃~60℃ USB output:5V/2A Max Dimension:13.4*7*3.3cm Specifications of 100A:
Rated voltage:12V/24V
Charging Mode:PWM MPPT
Rated current :100A
Max PV VOTAGE:50V
Max PV input Power:360W(12V) 720(24V)
colour: orange
Material: Plastic
size: 133x70x35mm/5.24”*2.76”*1.38”
Display: LCD screen
Self-consumption: <10MA
Overcharge protection: 14.4V / 28.8V
Overcharge Float charge: 13.7V / 27.4V
Charge recovery voltage: 12.6V / 25.2V
Over discharge protection: 10.7V / 21.4V
Over discharge recovery: 12.6V / 25.2V
Dual USB output: 5V / 2A (charge mobile phone, iPad, etc.)
Working temperature: -35 ℃ -60 ℃
12V fits 18V solar panel, 24V fits 36V solar panel
12.0 volt lead acid battery corresponding
The float voltage is set to: 13.6
The recovery discharge voltage is set to: 12.6
The discharge cut-off voltage is set to: 10.7
12.8 volt lithium iron phosphate battery corresponding
The float voltage is set to: 14.6
The recovery discharge voltage is set to: 13.6
The discharge cut-off voltage is set to: 11.0
11.1 volt lithium battery corresponding
The float voltage is set to: 12.6
The recovery discharge voltage is set to: 11.6
The discharge cut-off voltage is set to: 9.6
The minute is adjustable when the output is turned off, which is more convenient (there is no adjustment when the market is only available). Package includes: 1 x Solar Charge Controller 1 x User Manual Payment Shipping Return Policy About Us Contact Us Payment *** We accept Paypal,Visa,Credit Card, e-Check . etc. Shipping Below is the approximate delivery time to different countries (Just estimated)
