175W 12V Volt Mono-crystalline Solar Panel Off Grid PV Power Boat
RooftopUSD $186.25
Condition : New
Free Shipping
{{variant_type_name}} :
Notify me when the price drops
We will email you if we find a lower price on this product!
Product details
Compact, lightweight, and reliable. This Renogy 175 Watt 12 Volt Monocrystalline Solar Panel can provide an average of 875 Watt-hours (Wh) of electric power per day (depending on sun availability). This panel features an extended lifespan for outdoor use and high resistance against wind and snow, enabling wide applications including the rooftop, cabin, RV, boat, and more. Perfect choice to build up your first solar system or expand your power generating capacity. Since 2010, Renogy has gained rich experience designing and manufacturing the most efficient and robust solar panels and complete off-grid solar systems. Renogy's focus on testing, quality control, and traceability ensures our solar power system offers industry-leading reliability. Invest in yourself by going Renogy. Renogy solar panels will be your most economical long-term investment yet. 【Reliable Power Output】 This panel can provide 875 Watt-hours (Wh) of electricity per day (depending on sun availability). Guaranteed positive output tolerance (0-3%). 【High Efficiency】
Mono cell, EL tested, no hot-spot heating, durable TPT back sheet, prevent dissipation of power to keep high efficiency and enhance longevity. Bypass diodes minimize power drop caused by shade and ensure excellent performance in low-light environments. 【Rugged Structure】 Corrosion-resistant aluminum frame, low-iron tempered glass. Back up your adventures with enhanced stiffness and impact resistance. 【Weatherproof】 IP65 junction box provides complete protection against environmental particles and low-pressure water jets. Withstand high winds (2400Pa) and snow loads (5400Pa). 【Easy Installation】
Pre-drilled holes on the back frame allow for fast mounting and securing. Compatible with Renogy ground mounts, Z Brackets, Corner Brackets, Pole Mounts, and Tilt Mounts. Pre-installed corner protectors protect you from sharp corners and the solar panel frame from accidental impacts and failure. Specifications: Electrical
Max Power at STC: 175W
Open Circuit Voltage: 21.6 V
Short Circuit Current: 10.31 A
Optimum Operating Voltage: 18.1 V
Optimum Operating Current: 9.67 A
Module Efficiency: 19.80%
Cell Efficiency: 22.00%
Maximum System Voltage: 600 VDC UL
Maximum Series Fuse Rating: 20 A Mechanical
Cell Type: 166
Number of Cells: 64(4*16)
Dimensions: 49.7x27.5x1.38 in ( 1262x699x35mm )
Weight: 22lbs (10kg)
Front Glass: Tempered Glass 0.13 in (3.2 mm）
Frame : Anodized Aluminium Allo
Connectors: Solar Connectors
Panel Leads (Pair): 13 AWG x 2.3 Ft
Fire Rating: Class C Thermal Characteristics
Operating Temperature: -40°F to 176°F (-40°C to 80°C)
Nominal Operating Cell Temerature (NOCT): 45 ± 2 °C
Temperature Coefficient of Pmax: -0.37%/°C
Temperature Coefficient of Voc: -0.28%/°C
Temperature Coefficient of Isc: 0.048%/°C Solar Connectors
Rated Current : 35A
Maximum Voltage: 1000V
Maximum AWG Size Range: 12AWG
Temperature Range: ﹣40℃ ～ +90℃
IP Rating: IP68 Junction Box
IP Rating: IP 65
Diode Type: 20SQ045
Number of Diodes: 2 Diode(s)
Output Cables: 13 AWG(2.3 ft long) Package Includes:1 x 175 Watt Solar Panel
Compact, lightweight, and reliable. This Renogy 175 Watt 12 Volt Monocrystalline Solar Panel can provide an average of 875 Watt-hours (Wh) of electric power per day (depending on sun availability). This panel features an extended lifespan for outdoor use and high resistance against wind and snow, enabling wide applications including the rooftop, cabin, RV, boat, and more. Perfect choice to build up your first solar system or expand your power generating capacity. Since 2010, Renogy has gained rich experience designing and manufacturing the most efficient and robust solar panels and complete off-grid solar systems. Renogy's focus on testing, quality control, and traceability ensures our solar power system offers industry-leading reliability. Invest in yourself by going Renogy. Renogy solar panels will be your most economical long-term investment yet. 【Reliable Power Output】 This panel can provide 875 Watt-hours (Wh) of electricity per day (depending on sun availability). Guaranteed positive output tolerance (0-3%). 【High Efficiency】
Mono cell, EL tested, no hot-spot heating, durable TPT back sheet, prevent dissipation of power to keep high efficiency and enhance longevity. Bypass diodes minimize power drop caused by shade and ensure excellent performance in low-light environments. 【Rugged Structure】
Pre-drilled holes on the back frame allow for fast mounting and securing. Compatible with Renogy ground mounts, Z Brackets, Corner Brackets, Pole Mounts, and Tilt Mounts. Pre-installed corner protectors protect you from sharp corners and the solar panel frame from accidental impacts and failure. Specifications: Electrical
Max Power at STC: 175W
Open Circuit Voltage: 21.6 V
Short Circuit Current: 10.31 A
Optimum Operating Voltage: 18.1 V
Optimum Operating Current: 9.67 A
Module Efficiency: 19.80%
Cell Efficiency: 22.00%
Maximum System Voltage: 600 VDC UL
Maximum Series Fuse Rating: 20 A Mechanical
Cell Type: 166
Number of Cells: 64(4*16)
Dimensions: 49.7x27.5x1.38 in ( 1262x699x35mm )
Weight: 22lbs (10kg)
Front Glass: Tempered Glass 0.13 in (3.2 mm）
Frame : Anodized Aluminium Allo
Connectors: Solar Connectors
Panel Leads (Pair): 13 AWG x 2.3 Ft
Fire Rating: Class C Thermal Characteristics
Operating Temperature: -40°F to 176°F (-40°C to 80°C)
Nominal Operating Cell Temerature (NOCT): 45 ± 2 °C
Temperature Coefficient of Pmax: -0.37%/°C
Temperature Coefficient of Voc: -0.28%/°C
Temperature Coefficient of Isc: 0.048%/°C Solar Connectors
Rated Current : 35A
Maximum Voltage: 1000V
Maximum AWG Size Range: 12AWG
Temperature Range: ﹣40℃ ～ +90℃
IP Rating: IP68 Junction Box
IP Rating: IP 65
Diode Type: 20SQ045
Number of Diodes: 2 Diode(s)
Output Cables: 13 AWG(2.3 ft long) Package Includes:
Returns Accepted for this item if it's within 30 Days
