175W Watt 12V 248° Flexible Mono Solar Panel for RV Rooftop Boat Off
GridUSD $250.18
Condition : New
Free Shipping
{{variant_type_name}} :
Notify me when the price drops
We will email you if we find a lower price on this product!
Product details
Lightweight, thin, and capable of flexing up to 248 degrees, this Renogy 175W Flexible Solar Panel is your perfect solution for a power-independent journey! IP68 junction box and IP67 solar connector, excellent weatherproof performance, perfect for marine and outdoor use. At a weight of 6.2 lbs, this flexible solar panel weighs 70% less than its rigid counterpart, making it an ideal alternative for load-sensitive structures and uneven surfaces. Perfect for RVs, campers, boats, and many others. If you want to keep the speed of your vehicles and enjoy off-grid power freedom, this is your best solution.Mounting Recommendation: Modules must be mounted using silicone structural adhesive on the backside of the panel, grommets are only to be used for non-mobile applicatFor detailed installation methods, please consult a local contractor for guidance.
Renogy 175W Flexible Solar Panel - 【Extremely Flexible】
This 175W solar panel can flex up to 248 degrees, minimizing the mounting and even issues for a curved surface. Where rigid panels are inconvenient to install, get this one. 【Ultra Lightweight】
Light as 6.2 pounds, this 175W flexible panel weighs 70% less than its rigid counterpart. Reduce your burden on the road, embrace new possibilities. 【Super Thin Lamination】
This Renogy 175W flexible panel is only 0.08 inches thick! It is about 95% thinner than its rigid counterpart, ideal for a stealthy solar setup. 【Weather Resistance】
Designed to withstand extreme wind of up to 2400Pa and snow loads of up to 5400Pa. Reliable in harsh environments. Back up your brave journey. 【Easy Installation】
Six metal reinforced mounting holes, simple to install. You can also mount it with silicone structural adhesive. Specifications: Electrical
Max Power at STC: 175W
Open Circuit Voltage: 23.9V
Short Circuit Current: 9.50A
Opitmum Operating Voltage: 19.5V
Optimum Operating Current: 8.98A
Module Efficiency: 17.3%
Maximum System Voltage: 600 VDC UL
Maximum Series Fuse Rating: 15A Mechanical
Cell Type: Monocrystalline (6.17 x 6.17 in)
Number of Cells: 36 (4 x 9)
Dimensions: 59.2 x 26.5 x 0.08 in (1504 x 673 x 2 mm)
Weight: 6.2 lbs (2.8 kg) Thermal Characteristics
Operating Temperature: -40°F to 185°F(-40ºC to +85ºC)
Nominal Operating Cell Temerature (NOCT): 45±2ºC
Temperature Coefficient of Pmax: -0.42%/C
Temperature Coefficient of Voc: -0.31%/C
Temperature Coefficient of Isc: 0.05%/C Solar Connectors
Rated Current: 30A
Maximum Voltage: 1000VDC
Maximum AWG Size Range: 10AWG
Temperature Range: -40ºF to 194ºF
IP Rating: IP 67 Junction Box Dimension
IP Rating: IP68
Number of Diodes: 2 Diode(s)
Output Cables: 12 AWG (2.30 ft long) Package Includes:
1 X Solar Panel
Lightweight, thin, and capable of flexing up to 248 degrees, this Renogy 175W Flexible Solar Panel is your perfect solution for a power-independent journey! IP68 junction box and IP67 solar connector, excellent weatherproof performance, perfect for marine and outdoor use. At a weight of 6.2 lbs, this flexible solar panel weighs 70% less than its rigid counterpart, making it an ideal alternative for load-sensitive structures and uneven surfaces. Perfect for RVs, campers, boats, and many others. If you want to keep the speed of your vehicles and enjoy off-grid power freedom, this is your best solution.Mounting Recommendation: Modules must be mounted using silicone structural adhesive on the backside of the panel, grommets are only to be used for non-mobile applicatFor detailed installation methods, please consult a local contractor for guidance.
Renogy 175W Flexible Solar Panel - 【Extremely Flexible】
This 175W solar panel can flex up to 248 degrees, minimizing the mounting and even issues for a curved surface. Where rigid panels are inconvenient to install, get this one. 【Ultra Lightweight】
Light as 6.2 pounds, this 175W flexible panel weighs 70% less than its rigid counterpart. Reduce your burden on the road, embrace new possibilities. 【Super Thin Lamination】
This Renogy 175W flexible panel is only 0.08 inches thick! It is about 95% thinner than its rigid counterpart, ideal for a stealthy solar setup. 【Weather Resistance】
Designed to withstand extreme wind of up to 2400Pa and snow loads of up to 5400Pa. Reliable in harsh environments. Back up your brave journey. 【Easy Installation】
Six metal reinforced mounting holes, simple to install. You can also mount it with silicone structural adhesive. Specifications: Electrical
Max Power at STC: 175W
Open Circuit Voltage: 23.9V
Short Circuit Current: 9.50A
Opitmum Operating Voltage: 19.5V
Optimum Operating Current: 8.98A
Module Efficiency: 17.3%
Maximum System Voltage: 600 VDC UL
Maximum Series Fuse Rating: 15A Mechanical
Cell Type: Monocrystalline (6.17 x 6.17 in)
Number of Cells: 36 (4 x 9)
Dimensions: 59.2 x 26.5 x 0.08 in (1504 x 673 x 2 mm)
Weight: 6.2 lbs (2.8 kg) Thermal Characteristics
Operating Temperature: -40°F to 185°F(-40ºC to +85ºC)
Nominal Operating Cell Temerature (NOCT): 45±2ºC
Temperature Coefficient of Pmax: -0.42%/C
Temperature Coefficient of Voc: -0.31%/C
Temperature Coefficient of Isc: 0.05%/C Solar Connectors
Rated Current: 30A
Maximum Voltage: 1000VDC
Maximum AWG Size Range: 10AWG
Temperature Range: -40ºF to 194ºF
IP Rating: IP 67 Junction Box Dimension
IP Rating: IP68
Number of Diodes: 2 Diode(s)
Output Cables: 12 AWG (2.30 ft long) Package Includes:
1 X Solar Panel
