DOKIO 220w 18v Portable Foldable Solar Panel Kit (29x21inch, 11.7lb)

DOKIO 220w 18v Portable Foldable Solar Panel Kit (29x21inch, 11.7lb) Solar Charger with Controller 2 USB Output to Charge 12v Batteries/Power Station (AGM, Lifepo4) Rv Camping Trailer Emergency Power

【LIGHTWEIGHT AND ULTRA-THIN FOR EASIER MOVING】-- This solar panel packs 220W of power yet is only 1.1inch (2.8cm) thick and weighs only 11.7lb(5.3kg),Foldable Dimension:29*21*1.1inch (73*54*2.8cm), making it easier to transport, hang, and remove.

【PERFECT CHOICE FOR OUTDOOR AND EMERGENCY LIFE】-- 9.85ft (3m) cable length from panel to controller, For most power stations (Jackery,Goal Zero,Ecoflow,Paxcess) and 12-volt batteries(AGM,LiFePo4,Deep cycle batteries),RV,car,boat,trailer,truck,pumpa,camping,van,emergency power

【COMPLETE KIT，WORKS OUT OF THE BOX 】-- Smart PWM charging Intelligent protection against reverse polarity, overcharging, short-circuit, and reverse current.Integrated 5V 2A USB ports to charge phones USB devices.If you use the built-in MPPT Power Station, you don't need to connect the attached PWM controller.

【AFFORDABLE AND HIGH CONVERSION EFFICIENCY】-- With high efficiency monocrystalline solar cell, you will get greater power efficiency even though the panel is smaller than a traditional model.Maximizes system output by reducing mismatch loss.

【QUICK DELIVERY+WARRANTY】-- Amazon US warehouse shipping, Receive goods in time，All DOKIO products come with a 30-day money back Guarantee, 1-year warranty and forever support from DOKIO customer care.

Product Description The cables are 9.84ft, to be long enough to position the panel to catch the best sun and to connect to a device that is not very portable. The solar panel has the best charging efficiency at a 90-degree angle to the sunlight.
HIGHER CONVERSION EFFICIENCY The monocrystalline silicon solar cells provide conversion efficiency of 23%, higher than other conventional panels.
SAFE CE Certification ISO Certification Overcharging Protection Overcurrent Protection Short Circuit Protection Overload Protection
AFFORDABLE & COMPLETE KIT A: 1*DOKIO 220W solar panel B: 1*DOKIO 20A controller C: 1* 9.8FT cable (SAE to XT60) D: 1*cable (XT60 to Alligator clip) E : 1 *c able (JY60 to DC) F: 5 * DC conversion adapters (8mm/6.4*4mm/5.5*2.5mm/5.5*2.1mm/3.5*1.35mm) FAQ: Q1: Can I connect panel to battery for charging directly without controller ? A1:
most power station is possible to do this.Because most of them have built-in MPPT,but the battery,Without the voltage regulation provided by the controller your chance of cooking the battery by overcharging is possible.
To charge a power station with a built-in controller, please do not connect the attached PWM controller. Q2: Why the solar can not produce 220W power when chargingto power station? A2:
As you know the solar panels are affected by many factors such as the light intensity and the panel's angle put on the ground. 220W is tested in an ideal laboratory. However, the intensity of the light constantly changes. In addition, the angel of the light illuminating the solar panel also changes with the rotation of the sun.Please try test your solar panel under the full sunlight to see, and make sure there is no shadow cast on the panel. Q3: Are this units waterproof?Can these solar panels be permanently instaled outside? A3:
Yes,lt is waterproof , BUT meant for temporary or emergency use only. Not designed for permanent installation or prolong weather exposure,DON'T leave them out at night or in bad weather. Using without batteries is primarily providing power to the USB ports(PWM controller). If you want higher power generation efficiency, you can buy MPPT and use it.Charge controllers reduce the wattages and amperage output as the batteries approach getting full In an ideal laboratory，220 Watts at 18 Volts(The panel rated voltage) yields 12 Amps, where I=P/V. Maximum Power 100W 150W 110W Dimension: 21x26x1.97inch (53x66x5cm) 26x30x2inch (75x66x5cm) 21x29x0.5inch (54x73x1.2cm) Weight: 18.5lb(8.4kg) 25lb(11.4kg) 6lb(2.7kg) Cable length 9.8ft (3m) ✓ ✓ ✓ Cell Type: Monocrystalline Monocrystalline Monocrystalline DC 18V Output: Alligator clip Alligator clip ✓ USB Port: 2x 2x 2x Controller 14.4V Output: ✓ ✓ ✓ Power Current: 5.56Ah 8.89Ah 6.1Ah Item model number Solar Panel-220w Style Battery Maximum Power 220 Watts Maximum Voltage 18 Volts Folded Knife Size 29x21x1.1in Country of Origin China Warranty Description Manufacturer warranty for 365 days from date of purchase Batteries Included? No Batteries Required? No Brand DOKIO Material Monocrystalline Silicon Efficiency High Efficiency Amperage Capacity 11.12 Amps Item Dimensions LxWxH 29 x 21 x 1.1 inches Is Discontinued By Manufacturer No Manufacturer DOKIO Item Package Quantity 1 Connector Type 5*DC conversion adapters (8mm/6.4*4mm/5.5*2.5mm/5.5*2.1mm/3.5*1.35mm), USB, SAE, XT60 Item Weight 10.56 Pounds Part Number FFSP-200 Color Black, Red Wattage 200 watts Shape Rectangle Included Components Bag Product Dimensions 29 x 21 x 1.1 inches Size 220W Shipping
