300W Flexible Solar Panel Mono 12V Home RV Boat Camping Power Battery

Product Description 300W/12V Flexible Monocrystalline Solar Panel

Solar panel consists of monocrystalline silicon solar cells.

Advanced technology contact cells allow for flexibility and increased wattage per square foot.

The high transmittance and flexible lamination material are less prone to breakage.

Outstanding electrical performance in high temperature and low light environments.

Bypass diodes minimize the drop in performance due to partial shade.

Resistant to water and UV rays.

Package Include

300W solar panel

600W solar panel

900W solar panel

1200W solar panel

Specification

Aximum power (Pmax): 300W

Output tolerance: ± 5%

Maximum Power Current(IMP)：17.24A

Maximum Power Voltage(VMP)：17.4V

Short Circuit Current(ISC)：18.27A

Open Circuit Voltage(vOc)：21.4V

Battery efficiency: 22%

Working Temperature：-20°C TO+60°C

Temperature range: -40℃～+80℃

Dimension：1030*530*3MM

Package Include
300W Solar Panel
600W Solar Panel
(2x300W solar panel) OR
900W Solar Panel
(3x300W solar panel) OR
1200W Solar Panel Kits
(4x300W solar panel)
Feature:

The solar system kit connection is divided into parallel connection or serial connection. The controller must be first connect the battery , and then connect the solar panels.

When the solar panels are connected in series or in parallel, paid to the highest PV input voltage of the controller. The voltage connected in parallel to the controller after the series connection cannot exceed the maximum input voltage of the controller.

When the cable is connected to each component, the connection should be stable and there should be no looseness.

The positive and negative poles of the controller and battery should be checked clearly. Do not reverse the positive and negative poles.

When the power rating of one controller is insufficient to meet all solar panels, please use multiple controllers

Conversion rate of monocrystalline solar panels is as high as 22%.
The junction box is waterproof with IP67. Built in blocking diode to prevent battery discharge at night.
The solar panel is with cable which is male and female connector
Solar panels are suitable for multiple scenarios, such as RV, yacht, ship, roof, etc.

Returns Accepted for this item if it's within 30 Days
