600W Grid Tie Inverter MPPT DC16-28V to AC110V for 12V Solar Panel 24V

600W Grid Tie Inverter MPPT DC16-28V to AC110V for 12V Solar Panel  24V Battery Send from USA,5-8 Workings Days Delivery with Tracking 600W Solar Grid Tie Inverter, MPPT Pure Sine Wave Inverter DC16V-28V to AC110V, 50Hz/60Hz Auto Solar Panel Voltage: Vmp18-21V; Voc20-24 Solar Panel Power: minimum 120W, maximum 650W with MPPT Functions and Stackable DC16-28V version is suitable for 12V solar panel (Vmp18-20V; Voc20-24V) Vmp = working voltage; Voc = open circuit voltage. The starting voltage of the inverter is 16V. Therefore, the DC11V input cannot be used. 32V is only an instantaneous voltage, used as a buffer protection, not as a working voltage input. Otherwise it will damage the inverter. The solar panel voltage will decrease with the intensity of the sunlight. After the inverter is started at 16V, it will work even if the panel voltage drops. We designed a wider voltage input range to allow the inverter to output more power. After the voltage is lower than 15V, the working efficiency will start to decline. Smart Microinverter Introduction:
Smart grid tie inverter is a compact unit, which directly converts direct current into alternating current for powering appliances and/or office equipments and connecting to utility grid. The AC output from Smart Microinverter is synchronized and in phase with the utility grid. It is a key device of power generation systems such as PV power generation system, wind turbine power generation system. Smart Microinverter specially optimized design to work with modularization of DC power supplies which includes the mainstream solar modules, 18V (36 cells)
monocrystal and/or Polycrystalline solar panels, wind turbines and batteries. Smart Microinverters are stabilization, reliable and high conversion efficiency items. It is the best choice for PV power generation systems. Advantages of Smart Microinverter:
1. Unique circuit design, choice of import industrial electronic components, higher efficiency, more stable performance.
2. Creative MPPT technology, efficiency more than 99%, faster and more sensitive reaction, more reliable.
3. Parallel type design for DC input and modularization design for inverter, small volume, distributed installation, easy for system configuration, flexible for combination, strong expansibility of system.
4. Adopting high-frequency isolation transformer type, high efficiency, and high security.
5. Perfect electrical protection function.
6. Aluminum alloy housing, not rust, heat-resisting and cold-resistant as well as anti-corrosion.
7. Getting electronic circuit design, appearance design and other core technology patents. Smart Microinverter Technical Parameters: Power 200W 300W 400W 500W 600W Solar panels ≥200W ≥300W ≥400W ≥500W ≥600W DC input range 16-28VDC MPPT Voltage 15-22V DC MAX current 12A 18A 25A 31A 38A AC MAX output 230W 330W 430W 550W 650W AC output range 120VAC(90-140VAC) Frequency range 50Hz/60Hz(Auto control) Power Factor >98% THD <5% Phase Shift <2% Efficiency 120VAC(90-140VAC) Version Peak Efficiency >90 >89 >88 >87 >86 Stable Efficiency >89 >88 >87 >86 >85 Efficiency 230VAC(190-260VAC) Version Peak Efficiency >91 >90 >89 >88 >87 Stable Efficiency >90 >89 >88 >87 >86 Protection Islanding; Short-circuit; Converse Connection; Low Voltage; Over Voltage; Over temperature Protection Work Temperature ‘-25 ℃ -65 ℃ Work Humidity 0%~90%RH non-condensing Grade of Waterproof Indoor design Show LED Cooling Fan Stand-by Power ＜ 1W EMC EN61000-6-3:2007 EN61000-6-1:2007 Grid Disturbance EN 50178+EN 62109-1+VDE0126-1-12 Grid Detection DIN VDE 1026 UL1741 Certificate CE This grid tie inverter cannot be used as off grid/stand alone solar system. The output need to be connected to the grid power. Can not supply power directly to the AC loads. DO NOT use solar controller load ports to connect to the inverter. Inverter Diagram： A. Inverter work with solar panels. 16-28VDC range is for 36cells-Vmp:18-21V:Voc:20-24V solar panels. 30-45VDC range is for 60cells-Vmp:26-30V:Voc:34-38V or 72cells-Vmp:35-39V:Voc:42-46V. This range can suitable for two version solar panels. B. Inverter work with battery. If you want to use this grid tie inverter for battery, then please use 24VDC battery with 16-28VDC inverter. 36VDC battery with 30-55VDC inverter. Because this inverter is designed for solar panels which with MPPT function. So we don't very suggest customers to use it for battery. It may short the inverter service life.If use a battery to power the inverter, please use a circuit breaker. What's In Box： 1 x 600W Solar Inverter 1 x English User's Manaul 1 x AC Cord(US) Shipping Policy: 1. Items are usually shipped 1-3 business days after payment has been received.We do not ship on weekends and holidays 2.Sellers are not responsible for service transit time. Transit times are provided by the carrier, exclude weekends and holidays, and may vary with package origin and destination, particularly during peak periods. 3. Delivery time depends on destination and other factors, it may takes up to 20 days. If you don't receive the item after 30 days, please contact us, we'll investigate and solve the delivery problem. 4.International buyers are responsible for duties and customs fees.We are not responsible for any customs duties or import taxes (if any) 5.Buyer from remote area should pay 35 USD more for the remote delivery service.(Only for Business Express ) Payment Method: 1. Payment methods accepted : Paypal only. 2. All major credit cards are accepted through our secure payment processor PayPal. 3. Payment must be received within 4 business days of auction closing. 4. We only ship to the confirmed address provided by ebay. Before you pay, please make sure your address in ebay matches the address you would like us to ship to. Returns Policy: 1.One Year Warranty. Buy with confidence! 2. Refund or replacement request is available only requests within a week after parcel received & returning the item as the same condition as received.Please include your eBay ID and brief description of defective problem in your return package. 3. Defective situation must be noticed within 7 days after delivery. 4. Buyer must pay the return postage for any return reason.In return,we will pay the shipping fee for send it back to you. 5.Replacement or refund will be issued after the items are recevied by us in good condition. Feedback: 1.We maintain all excellence 5 star DSR and strive for 100% customer satisfaction! Feedback is very important to us. 2.Please do not give us any bad feedback. Or contact us before you open a case. If you can do as we say, we will be very grateful.Please give us the opportunity to resolve any problem. Duties: 1.Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Please check with your country's' customs office to determine what these additional costs will be prior to bidding/buying. 2.These charges are normally collected by the delivering freight (shipping) company or when you pick the item up, do not confuse them for additional shipping charges. 3.Custom holds and delays vary from country to country and are beyond the control of the seller. Please do not hold us responsible for delivery delays caused by customs related issues. Thank You!

Returns Accepted for this item if it's within 30 Days
