Black+Red 10/12AWG Solar Panel Extension Cable Silicone Flexible

★ Application: Specially developed for the connection of components in a photovoltaic system outside of buildings and devices with high mechanical requirements and extreme weather Conditions. For permanent installations. ★ General characteristics: Cable made of electron beam cross-linked insulation and coating; high resistance to heat, cold, oil, abrasion, ozone, UV and weather; with improved reaction in case of fire. low smoke, halogen free, flame free, flame retardant; flexible, easy to remove, very little space required, extreme, extreme mechanically robust, very long life. 6 square single core photovoltaic cable (10 AWG) ● Nominal section: 6 mm2 ● Model: PV1-F ● Rated current: 70A ● Number of cores: NO. 1 ● Conductor: copper wire structure NO./mm 84 / 0.30 ● Conductor wire diameter: 3.42 mm ● Minimum insulation wall thickness: 0.5 mm ● Minimum wall thickness of the jacket: 0.5 mm ● Finished wire diameter: 6.9 ± 0.1 mm ● Conductor resistance (20 ℃): ≤ 3.39 Ω / km ● Test voltage kV / min: 6.5 / 5 No breakdown ● Nominal temperature: -40 ~ +90 ℃ ● Maximum conductor temperature: + 120 ° C. ● Permissible reference short-circuit temperature: 200 ℃ 5S ● Lifespan:> 25 years (-40 ~ +90 ℃) ● Nominal voltage: DC: 1.8 kV AC U / U: 0.6 / 1 kV ● Working environment temperature ℃: -40 ~ +90 ● Operating voltage AC / DC (KV): 0.6 ~ 1.0 / 1.8 ● Weather resistance: UV ● Flame retardant: single vertical combustion (IEC60332-1) ● Sun resistant test: HD605 / A1 ● Cable ozone resistance test: EN50396 ● Smoke density: IEC61034, EN50268-2 ● Halogen acid release: IEC670754-1 EN50267-2-1 ● Weight: 0.09 kg / m 4 square single-core photovoltaic cable （12AWG） Cutting area: 4.0 mm2 Rated current: 55A Nominal voltage: 600 V / 1800 V (AC / DC) Ambient temperature range: -40 ° C〜 + 125 ° C. Strand design (No.Xø (mm)): 56 / 0.30 Connector type: PV connector Conductor diameter: 2.06 mm, Outside diameter: 6.05 mm Product details Product No. PV connector B2 Nominal voltage TÜV 1000 V DC / UL 600 V DC Suitable cable cross-sections 2.5 mm2 ~ 6.0 mm2 / 14AWG ~ 10AWG Pin size 4.0 mm Test voltage DC 8KV (1min) Pollution degree 2 Protection class class II Contact material copper, tinned Contact resistance 5mW Connector material PPO Degree of protection IP IP67 (IEC 60529) Retraction force 3 50N Insertion force 50N Temperature range -40 ° C ~ + 85 ° C. Flame class UL94V - 0 Solar connection waterproof IP67. Package includ: A cable (with plug)
