Newpowa 20A MPPT 12V/24V Auto Switch Battery Regulator Charge

Newpowa 20A MPPT SOLAR CHARGE CONTROLLER
Newpowa 20 Amp MPPT Charge Controller applied Advanced Maximum Power Point Tracking (MPPT) technology to help regulate the power from your solar panel to battery with efficiency no less than 99.5%. This 20 Amp MPPT solar regulator adopts high quality components with maximum conversion efficiency of 98%. The MPPT battery charging can greatly increase the lifetime of your battery and has various unique functions and quite easy to use features.

Features:

• Advanced  technology with efficiency no less than 99.5%
• Maximum conversion efficiency of 98%
• Ultra-fast tracking speed and guaranteed tracking efficiency
• Accurately recognizing and tracking of multiple power points
• Wide MPP operating voltage range
• Support 4 charging options: Sealed, Gel, Flooded and User
• Battery temperature compensation function

Specification  Rated Current:                           20A  System Voltage:                        12V/24V(Auto)  Rated discharge current:             20A
  Battery voltage range:                 8V— 32V
  Max.PV open circuit voltage :     150V/138V
  MPP voltage range:                     Battery voltage +2V—108V
   Max.PV input power:                   260W(12V),520W(24V)
  Self-consumption:                       ≤60mA(12V); ≤30mA(24V)
  Working Temperatyre:                 -35℃— 55℃
  Storage Temperature:                 -35℃— 80℃
  Humidity:                                     ≤95%（N.C.）
  Dimension(L*W*H)(mm):            216.6*142.6*56
  Net Weight(Approx.):                  1.5Kg/3.3Lbs


Shipping Policy:

Newpowa-Solar offers free shipping for all domestic (lower 48 states) orders. Your order will be shipped within 1-2 business day once the payment is received. Please note that we won't be able to process any order with PO Box address for any size of solar panel. Upon shipment a tracking number will be provided for you. Adult Signature Required for deliveries.


Solar Controllers Warranty:
24 month limited materials and workmanship warranty
