- Renogy Wanderer Li 30A PWM Charge Controller -
categories Description
The Renogy Wanderer-Li is a 30A PWM solar charge controller that integrates efficient PWM charging to increase battery life and improve system performance. Designed with a simple interface for ease of use, the controller uses multiple LED indicators to notify users of charge status and battery information. This newly improved model has two advanced features: an RS232 port and Lithium battery charging. With the addition of the RS232 port, users can now connect and communicate with the
. By adding the BT-1 to the Wanderer-Li, you can now use the smartphone app, DC Home, to monitor and adjust your solar system remotely. With the inclusion of the Lithium Battery Mode, the 30A negative-ground controller is now capable of charging various 12V battery types and banks, including most 12V lithium models available on the market. Specification

  Nominal Voltage: 12V

  Max Gauge Size: Up to 8AWG

  Rated Charge Current: 30A

  Max. PV Power: 400W

  Max. PV Input Voltage: 25 VDC

  Dimensions: 6.45 x 4.31 x 1.76 in

  Weight: 0.65 lbs

Notes

  1. Installation Notes: The default starting position of the Wanderer controller terminal hatches are closed (in the UP position) that could mistakenly look like an open wire hatch. Make sure to FIRST lower each terminal hatch by screwing the terminals counterclockwise to expose the wire terminal hatch to the open position. THEN secure each cable by rotating the screws clockwise to the closed position.

  2. Simple Install: Fully open the hatch (CCW), insert the appropriate wires, and completely close the hatch (CW).

1-year Material and workmanship warranty

Optimized for a 12V system; Deep cycle Sealed, Gel, Flooded, and Lithium battery option ready.

Smart 4 Stage PWM charging (Bulk, Boost, Float, and Equalization) and temperature compensation increases battery life and improves system performance.

Intelligent protection against reverse polarity, overcharging, short-circuit, and reverse current. Multiple LED indicators for easy to read charge status and battery information.

Integrated RS232 port allows communication with

and usage of DC Home smartphone app.

Specification Manual Specification
Renogy Wanderer LI 30A PWM Solar Charge Controller Nominal System Voltage: 12V Rated Charge Current: 30A Max Gauge Size: Up to 8AWG Self-Consumption: ＜10mA Max. PV Input Power : 400W Max. PV Input Voltage: 25 VDC Working Temperature: -20°F - 113°F Dimensions: 6.45 x 4.31 x 1.76 in Weight: 0.65 lbs Storage Temperature: -31°F - 176°F High Voltage Disconnect: 16V Boost Duration: 120 min Enclosure: IP20 Compatible bluetooth: Renogy BT-1 Bluetooth module Temperature Compensation: -3mV/°C/2V Warranty FAQs
Q/A
1.What equipment does an off-grid solar system require?
Here’s a list of all the equipment required for a functioning off-grid solar system: Solar panels, Solar charge controller, inverter(s), battery, mounting and racking system, wiring cables and fuses.
